sand washing machine price description:
Firstly, please forgive me to introduce our company briefly, we have been specialized in manufacturing jaw crushers, cone crushers and whole crushing plant for 21 years; and have the exporting experience for 6 years. With the reliable quality, good prices and best after-sales services, our products are very hot sale in Asia, Africa and South America. So we really hope to be one of your best suppliers in near future.
Sand washer is a kind of water washing style equipment to be matched with the sand making machine and can reduce the dust and stone powder which mixes with the final sand, so sand washing machine can improve the quality of the sand. The materials include the required gravel in building-site, gravel factories, hydropower station and concrete dam site, post and electric pole factory, casting-70 sand, glass factory’s quartz sand and refilling pressure sand. Sand washer is mainly used in building site, gravel plant, concrete dam building site of hydropower station.
Technical Data of Bucket Wheel Sand Washer
| Model | Bucket wheel diameter
(mm) | Max feeding size
(mm) | Capacity
(t/h) | Speed
(r/min) | Power
(kw) | Overall dimension
(L×W×H)(mm) | Weight
(t) |
XS2600
| 2600 | ≤10 | 20-50 | 2.5 | 5.5 | 3550X2080X2650 | 2.67 |
XS2600II
| 2600 | ≤10 | 30-70 | 2.5 | 5.5 | 3550X2080X2650 | 2.9 |
XS2800
| 2800 | ≦10 | 50-100 | 1.2 | 11 | 3964x2137x2895 | 3.98 |
XS3200 | 3200 | ≤10 | 80-120 | 1.2 |
15 |
4346x2934x3345 | 7.27 |
XS3600 | 3600 |
≤10 |
120-180 | 1 |
15 | 4355X4505X3810 | 9.43 |
Technical data of spiral sand washer
| Model | Screw diameter(mm) | Length of Chute (mm) | Max feeding size(mm) | Capacity (t/h) | Speed (r/min) | Power (kw) | Water Consumption(t/h) | Overall dimension(L×W×H)(mm) | Weight(t) |
| XL508 | 508 | 6705 | ≦10 | 20 | 38 | 5.5 | 6-60 | 8000*2343*1430 | 2.67 |
| XL610 | 610 | 7225 | ≦10 | 40-50 | 32 | 7.5 | 6-63 | 8000*2050*1400 | 3.80 |
| XL762 | 762 | 7620 | ≦10 | 50-75 | 26 | 11 | 9-63 | 8545*2650*3862 | 5.23 |
| XL920 | 920 | 8026 | ≦10 | 100 | 18 | 11 | 10-80 | 8715X1632X2075 | 4.6 |
| 2XL920 | 920 | 8026 | ≦10 | 150-180 | 18 | 2*11 | 20-160 | 8715X2602X2075 | 7.9 |
| XL1115 | 1115 | 8532 | ≦10 | 175 | 18 | 15 | 20-150 | 9231X1833X2126 | 5.6 |
| 2XL1115 | 1115 | 8532 | ≦10 | 200-250 | 18 | 2*15 | 40-300 | 9231X2995X2126 | 10 |
|
|
High quality River sand washing machine price and gravel wash plant for sand processing plant Images
|
